| Description |
Details |
| Gigabit Ethernet ports |
24 |
| Uplink interfaces |
4 SFP+ |
| PoE+ power budget |
|
| Fanless |
Yes |
| Dimensions (WxDxH in inches) |
17.5 x 9.45 x 1.73 |
| Console ports |
RJ-45 Ethernet |
|
USB mini-B |
|
USB-A port for storage and Bluetooth console |
| Memory and processor |
|
| CPU |
ARM v7 800 MHz |
| DRAM |
512 MB |
| Flash memory |
256 MB |
| Performance |
|
| Forwarding bandwidth |
64 Gbps |
| Switching bandwidth |
128 Gbps |
| Forwarding rate (64-byte L3 packets) |
41.67 Mpps |
| Unicast MAC addresses |
16000 |
| IPv4 unicast direct routes |
542 |
| IPv4 unicast indirect routes |
256 |
| IPv6 unicast direct routes |
414 |
| IPv6 unicast indirect routes |
128 |
| IPv4 static routes |
16 |
| IPv6 static routes |
16 |
| IPv4 multicast routes and IGMP groups |
1024 |
| IPv6 multicast groups |
1024 |
| IPv4/MAC security ACEs |
600 |
| IPv6 security ACEs |
600 |
| Maximum active VLANs |
256 |
| VLAN IDs available |
4094 |
| Maximum STP instances |
64 |
| Maximum SPAN sessions |
4 |
| MTU-L3 packet |
9198 bytes |
| Jumbo Ethernet frame |
10,240 bytes |
| Dying Gasp |
Yes |
| MTBF in hours (data) |
2,026,793 |
| MTBF in hours (PoE) |
698,220 |
| MTBF in hours (Full PoE) |
698,220 |
| Environmental |
|
| Operating temperature Seal level |
-5 to 50 deg C* |
|
Up to 5,000ft (1500 m) |
|
-5 to 45 deg C |
|
Up to 10,000 (3000 m) |
|
-5 to 40 deg C |
| Operating altitude |
10,000 ft (3,000m) |
| Operating relative humidity |
5% to 90% at 40C |
| Storage temperature |
-13 to 158F (-25 to 70C) |
| Storage altitude |
15,000 ft (4500m) |
| Storage relative humidity |
5% to 95% at 65C |
| Safety and compliance |
|
| Safety |
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second |
|
Edition, EN 60950-1 Second Edition, IEC 60950-1 Second |
|
Edition, AS/NZS 60950-1, IEC 62368-1, UL 62368-1 |
|
GB 4943.1-2011 |
| EMC: Emissions |
47CFR Part 15 Class A, AS/NZS CISPR32 Class A, CISPR32 Class |
|
A, EN55032 Class A, ICES-003 Class A, VCCI-CISPR32 Class A, |
|
EN61000-3-2, EN61000-3-3, KN32 Class A, CNS13438 Class A |
| EMC: Immunity |
EN55024 (including EN 61000-4-5), EN300386, KN35 |
| Environmental |
Reduction of Hazardous Substances (RoHS) including Directive |
|
2011/65/EU |
| Telco |
Common Language Equipment Identifier (CLEI) code |
| U.S. government certifications |
TBD |
| Connectors and interfaces |
Ethernet interfaces |
|
|
|
– 10BASE-T ports: RJ-45 connectors, 2-pair Category 3, 4, or |
|
5 Unshielded Twisted Pair (UTP) cabling |
|
|
|
– 100BASE-TX ports: RJ-45 connectors, 2-pair Category 5 UTP |
|
cabling |
|
|
|
– 1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP |
|
cabling |
|
|
|
– 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair |
|
Category 5 UTP cabling |
| Indicator LEDs |
|
|
– Per-port status: link integrity, disabled, activity |
|
|
|
– System status: system |
| Console cables |
|
|
– CAB-CONSOLE-RJ45 Console cable 6 ft. with RJ-45 |
|
|
|
– CAB-CONSOLE-USB Console cable 6 ft. with USB Type A and |
|
mini-B connectors |
| Power |
|
|
– Use the supplied AC power cord to connect the AC power |
|
connector to an AC power outlet |
|
|
|
– Models have an external power supply |
