Essentials
|
|
| Product Collection |
11th Generation Intel® Core™ i5 Processors |
| Code Name |
Products formerly Tiger Lake |
| Vertical Segment |
Mobile |
| Processor Number |
i5-1135G7 |
| Lithography |
10 nm SuperFin |
| Recommended Customer Price |
$340.00 |
| CPU Specifications |
|
| Total Threads |
8 |
| Max Turbo Frequency |
4.20 GHz |
| Cache |
8 MB Intel® Smart Cache |
| Bus Speed |
4 GT/s |
| Configurable TDP-up Base Frequency |
2.40 GHz |
| Configurable TDP-up |
28 W |
| Configurable TDP-down Base Frequency |
900 MHz |
| Configurable TDP-down |
12 W |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
| Supplemental Information |
|
| Marketing Status |
Discontinued |
| Launch Date |
Q3’20 |
| Embedded Options Available |
No |
| Datasheet |
View now |
| Memory Specifications |
|
| Max Memory Size (dependent on memory type) |
64 GB |
| Memory Types |
DDR4-3200, LPDDR4x-4267 |
| Max # of Memory Channels |
2 |
| ECC Memory Supported |
No |
| GPU Specifications |
|
| GPU Name |
Intel® Iris® Xe Graphics |
| Graphics Max Dynamic Frequency |
1.30 GHz |
| Graphics Output |
eDP 1.4b, MIPI-DSI 2.0, DP 1.4, HDMI 2.0b |
| Execution Units |
80 |
| Max Resolution (HDMI) |
4096×2304@60Hz |
| Max Resolution (DP) |
7680×4320@60Hz |
| Max Resolution (eDP – Integrated Flat Panel) |
4096×2304@60Hz |
| DirectX* Support |
12.1 |
| OpenGL* Support |
4.6 |
| OpenCL* Support |
3.0 |
| Multi-Format Codec Engines |
2 |
| Intel® Quick Sync Video |
Yes |
| Intel® Clear Video HD Technology |
Yes |
| # of Displays Supported |
4 |
| Device ID |
0x9A49 |
| Expansion Options |
|
| Intel® Thunderbolt™ 4 |
Yes |
| Microprocessor PCIe Revision |
Gen 4 |
| Chipset / PCH PCIe Revision |
Gen 3 |
| Package Specifications |
|
| Sockets Supported |
FCBGA1449 |
| Max CPU Configuration |
1 |
| T-JUNCTION |
100°C |
| Package Size |
45.5×25 |
| Advanced Technologies |
|
| Intel® Gaussian & Neural Accelerator |
2.0 |
| Intel® Smart Sound Technology |
Yes |
| Intel® Wake on Voice |
Yes |
| Intel® High Definition Audio |
Yes |
| MIPI SoundWire* |
1.1 |
| Intel® Adaptix™ Technology |
Yes |
| Intel® Optane™ Memory Supported |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Hyper-Threading Technology |
Yes |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512 |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel® Volume Management Device (VMD) |
Yes |
| Security & Reliability |
|
| Intel® Control-Flow Enforcement Technology |
Yes |
| Intel® Total Memory Encryption |
No |
| Intel® AES New Instructions |
Yes |
| Intel® Software Guard Extensions (Intel® SGX) |
No |
| Intel® Trusted Execution Technology |
No |
| Intel® OS Guard |
Yes |
| Intel® Boot Guard |
Yes |
| Mode-based Execute Control (MBEC) |
Yes |
| Intel® Stable IT Platform Program (SIPP) |
No |
| Intel® Virtualization Technology (VT-x) |
Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® VT-x with Extended Page Tables (EPT) |
Yes |
