Specifications
-
Capacities8TB | 4TB | 2TB | 1TB
-
Form FactorM.2 2280
-
InterfacePCIe Gen4x4
-
Performance1TB—Sequential read up to 7400MB/s, sequential write up to 6500MB/s¹
2TB—Sequential read up to 7400MB/s, sequential write up to 6500MB/s¹
4TB—Sequential read up to 7400MB/s, sequential write up to 6500MB/s¹
8TB—Sequential read up to 7400MB/s, sequential write up to 6500MB/s¹ -
Operating Temperature0°C to 70°C (32°F to 158°F)
-
Storage Temperature-40°C to 85°C (-40°F to 185°F)
-
Dimensions (L x W x H)80 x 22 x 2.45 mm (3.15” x 0.87” x 0.10”)
-
Weight6g / 0.013 lbs
-
Warranty5-year limited warranty
-
Shock-resistant1500G, duration 0.5ms, Half Sine Wave
-
Vibration-resistant10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X,Y,Z)
-
TBW512GB: 500TBW, 1TB: 1000TBW, 2TB: 1500TBW, 4TB: 3000TBW
-
MTBF1,500,000 Hours
1 Up to 7400MB/s read transfer, write transfer speeds lower. Speeds based on internal testing. Actual performance may vary.
2 Comparison based on internal testing. Actual performance may vary.
3 4TB support NVMe 2.0 technology standard,512GB-2TB support NVMe 1.4 technology standard
Security safeguards, by their nature, are capable of circumvention. Lexar does not guarantee data will be 100% secure from unauthorized access, alteration, or destruction.
Actual usable memory capacity may vary. 1GB equals 1 billion bytes.
Lexar is not liable for any loss of data or images.
