Specifications
From The Manufacturer:
DES-1016A Switch Specifications:
| Feature | Description |
|---|---|
| Alarm Port | Not present |
| CompactFlash (CF) Card Slot | Not present |
| Console Port | Not present |
| RJ-45 Management Port | Not present |
| Secure Digital (SD) Card Slot | Not present |
| Dimensions | Not specified |
| Fan | Fanless |
| Humidity | * Operating: 10% ~ 90% RH * Storage: 5% ~ 90% RH |
| Interfaces | 16 x 100Base-TX |
| Auto MDI/MDIX | Yes (assumed based on common features for network switches) |
| Maximum Forwarding Rate | 2.38 Mpps |
| Maximum Power Consumption | 2.69 W |
| Packet Buffer Size | 2 MB |
| Power Input | 100 to 240 V AC |
| Switching Capacity | 3.2 Gbps |
| Temperature | * Operating: 0 ~ 40 °C * Storage: – 40 ~ 70 °C |
| Weight | 0.27 kg |
